GENERAL FEATURES

Min / Max Thickness              : 0.3 mm

Max Width                             : 1600 mm

Material                                  : Cold, Hot Sheet And Galvanized Coated Sheet

Max. Tensile Strength             : 42 Kg/mm²

Max. Yield Strength                : 36 Kg/mm²

Max. Input Roll Weight          : 20 Tons

Uncoiler Inner Diameter        : 508 mm – 610 mm

Max. Uncoiler Outer Diameter: 1900 mm

Recoiler Coil

Max. Recoiler Roll Weight: 20 Tons

Max Recoiler Roll Inner Diameter: 508 mm

Max. Recoiler  Roll Outer Diameter: 1900 mm

Strip

Min. Strip Wıdth:25 mm

Strip Cutting Accuracy:+/- 0.25 mm

Strip Cutting Method: Circular Rotary Knife

Strip Cutting Direction: Optional

Strip General Tolerance:± 1 mm

General

Max Line Speed:225 Mpm

Max. Slitting qty:26 slit

Lubricating: Automatic

Total Power:~320 Kw

Control System: Control Technique

Max. Hydraulic Pressure:100 Kg / cm²

Air Pressure And Consumptıon:5-8 Kg / cm² ,1000 L / Min.

Total Area: B=~25 M, E=~12.5 M, Y=~3m

Total Weight:~58 tons
