TECHNICAL DESCRIPTION

Suitable material: S700MC

(ISO, ATM, JIS, EN norm)

Material thickness: 1.5~8.0mm

Material width: 500~2,000mm

T.S.: Max. 850Mpa (1.5~4.0mm)

Max. 700Mpa (4.1~8.0mm)

Y.S.: Max. 700Mpa (1.5~4.0mm)

Max. 560Mpa (4.1~8.0mm)

Elongation: <= 30%

Oily: Dry or slight oily

Coil I.D.: φ508mm/ φ610mm (with rubber sleeve)

/φ762mm (with steel sleeve)

Coil O.D.: 900-2,100mm

Coil weight: 25 Ton for φ508mm

35 Ton for φ610mm /φ762mm

Cut length: 800mmL～12,000mmL

Stacking height: Max. 550mm (include pallet)

Stacking weight: Max. 10,000 kgs (include pallet)

Line speed: 0~60 m/min @ 1.5~4.0mm

0~30 m/min @ 4.0~8.0mm

SPM: Max. 50 sheet per minute

Loading speed: 0~15 m/min

Material requirements: Flatness ≤2%

Thickness difference: ≤5%

Bowness≤5%

Except the first and last few sheets, all the material capable with the above requirements,

we guarantee the tolerance as follow: but reference sheet width more than 600mm

For straight length measurement: 8,00 to 4,000mm == +- 1.0mm

4,001 to 8,000mm == + - 2.0mm

8,001 to 12,000mm == +- 3.0mm

Diagonal: 800 to 1000 == + 2.00 (max)

1001 to 1500 == + 3.00 (max)

1501 to 2000 == + 5.00 (max)
